Obtaining the Cluster ID

A cluster ID (cluster_id) is required for some URLs when an API is called. To obtain the cluster ID, perform the following steps:

Obtaining the Cluster ID by Calling an API

You can obtain the cluster ID by calling the Querying the Cluster List API.

The API for obtaining the cluster ID is GET https://{Endpoint}/v1.0/{project_id}/clusters, where {Endpoint} indicates the IAM endpoint, which can be obtained from Regions and Endpoints. For the project ID, see Obtaining a Project ID and Name. For API authentication, see Authentication.

The following is an example response. The value of id under clusters is the cluster ID.

{
  "totalSize" : 1,
  "clusters" : [ {
    "datastore" : {
      "type" : "elasticsearch",
      "version" : "7.10.2",
      "subVersion" : "7.10.2_24.3.0_0827",
      "isEosCluster" : false,
      "supportSecuritymode" : false
    },
    "instances" : [ {
      "status" : "200",
      "type" : "ess",
      "id" : "{INSTANCE_ID}",
      "name" : "css-8bc5-ess-esn-1-1",
      "specCode" : "ess.spec-4u8g",
      "azCode" : "{AZ_CODE}",
      "volume" : {
        "type" : "ULTRAHIGH",
        "size" : 40,
        "resourceIds" : [ "{RESOURCE_ID}" ]
      },
      "ip" : "192.168.0.122",
      "resourceId" : "{RESOURCE_ID}"
    } ],
    "publicKibanaResp" : {
      "eipSize" : 10,
      "publicKibanaIp" : "100.95.152.28:9200",
      "elbWhiteListResp" : null,
      "bandwidthResourceId" : "18bec13f-5cc1-4631-867f-33505d15be12"
    },
    "elbWhiteList" : {
      "whiteList" : "",
      "enableWhiteList" : false
    },
    "updated" : "2023-10-09T02:07:13",
    "name" : "css-8bc5",
    "publicIp" : "100.85.222.202",
    "created" : "2023-10-09T02:07:13",
    "id" : "{CLUSTER_ID}",
    "status" : "200",
    "endpoint" : "192.168.0.122:9200",
    "vpcId" : "{VPC_ID}",
    "subnetId" : "{SUBNET_ID}",
    "securityGroupId" : "{SECURITY_GROUP_ID}",
    "bandwidthResourceId" : "{BANDWIDTH_RESOURCE_ID}",
    "bandwidthSize" : 3,
    "httpsEnable" : true,
    "authorityEnable" : true,
    "diskEncrypted" : false,
    "backupAvailable" : false,
    "actionProgress" : { },
    "actions" : [ ],
    "enterpriseProjectId" : "0",
    "tags" : [ ],
    "period" : true
  } ]
}

Obtaining the Cluster ID from the GaussDB(DWS) Console

Log in to the CSS management console.
In the navigation pane on the left, click Clusters.
In the cluster list, find the target cluster and click the cluster name. The Cluster Information page is displayed.
Check the cluster ID under cluster information.
Figure 1 Checking the cluster ID

Parent topic: Appendixes
